| Quantity: | |
|---|---|
SMLSCO-123
SMLSCO
DN8-DN450
woven bag or as per customer’s
FOB/CFR/CIF，etc
T/T, L/C or as negotiation
Grade | TP304L,TP316L,TP317L,TP321/321H,TP310S,TP316Ti ,TP347H |
Standard | ASTM A312 |
Size | OD:13.7-457.2mm |
WT:2.11--23.83mm | |
Length:6M,12M,5-7Mrandom length,According to customer requirements | |
Process | Cold drawn,cold rolled |
Package | Woven bags |
End | PE/BE |
| Seamless Pipe Chemical Composition | |||||||||
| C(max) | Si(max) | Mn(max) | P(max) | S(max) | Cr | Ni | Mo | Ti | |
| TP304/1.4301 | 0.08 | 1 | 2 | 0.045 | 0.03 | 18.0-20.0 | 8.0-10.5 | ||
| TP304L/1.4307 | 0.035 | 1 | 2 | 0.045 | 0.03 | 18.0-20.0 | 8.0-12.0 | ||
| TP304H/1.4948 | 0.04-0.10 | 1 | 2 | 0.045 | 0.03 | 18.0-20.0 | 8.0-12.0 | ||
| TP316/1.4401 | 0.08 | 1 | 2 | 0.045 | 0.03 | 16.0-18.0 | 11.0-14.0 | 2.0-3.0 | |
| TP316L/1.4404 | 0.035 | 1 | 2 | 0.045 | 0.03 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | |
| TP316Ti/1.4571 | 0.08 | 1 | 2 | 0.045 | 0.03 | 16.0-18.0 | 10.0-14.0 | 2.0-3.0 | 0.7>5x(C+N) |
| TP321/1.4541 | 0.08 | 1 | 2 | 0.045 | 0.03 | 17.0-19.0 | 9.0-12.0 | 0.7>5x(C+N) | |
| TP317L/1.4449 | 0.08 | 1 | 2 | 0.045 | 0.03 | 18.0-20.0 | 11.0-14.0 | 3.0-4.0 | |
| TP347H/1.4912 | 0.04-0.10 | 1 | 2 | 0.045 | 0.03 | 17.0-19.0 | 9.0-13.0 | ||
| TP309S/1.4833 | 0.08 | 1 | 2 | 0.045 | 0.03 | 22.0-24.0 | 12.0-15.0 | 0.75 | |
| TP310S/1.4845 | 0.08 | 1 | 2 | 0.045 | 0.03 | 24.0-26.0 | 19.0-22.0 | 0.75 | |
Construction building material, curtain wall bracket, guardrail/handrailing material,
petroleum oil and gas transmission, coal, decoration, chemical engineering, food
processing, agricultural use, indoor pipeline, water heater, boiler, etc.
Packaging Details:Woven bags or according to customer requirements
Port:SHANGHAI/NINGBO
FAQ:
A: We are factory.
A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.
