| Quantity: | |
|---|---|
TP316/L
ISO, PED
DN8-DN450
woven bag or as per customer’s
FOB/CFR/CIF，etc
T/T, L/C or as negotiation
 |  |
Material:
Stainless Steel 304 / 316
Standard:
ASTM A351 CF8 / CF8M
ISO 4144 / EN 10241
BSP threaded according to ISO 7-1 / EN 10226-1
Outer Diameter:
DN8 – DN100
Pressure Rating: Class 150 / PN10
Thread Standards: BSPT (British Standard Taper), NPT (National Pipe Taper), BSPP (British Standard Parallel)
Size Range: 1/8" ~ 4" (custom sizes available)
Working Temperature: -20°C to 200°C (depending on material and media)
Connection Types: Female Thread / Male Thread / Union / Weld End
| Step | Process Name | Description |
| 1 | Raw Material Preparation | Select stainless steel or brass; perform MTC & PMI inspection |
| 2 | Wax Pattern Making | Create precise wax models; assemble into wax trees (for investment casting) |
| 3 | Shell Building | Apply ceramic layers to build a strong mold shell |
| 4 | Dewaxing & Firing | Remove wax using steam; fire the shell at high temperatures |
| 5 | Metal Pouring (Casting) | Pour molten metal into shell molds; allow controlled cooling |
| 6 | Shell Removal & Cleaning | Break off ceramic shell; clean and sandblast or pickle the castings |
| 7 | CNC Machining & Threading | Precision machining, thread cutting (BSPT/NPT/BSPP) |
| 8 | Inspection | Perform dimensional, visual, thread, and optional PMI or pressure tests |
| 9 | Surface Treatment | Pickling, passivation, polishing or electroplating |
| 10 | Marking & Packaging | Laser/stamp marking; export packaging with labeling and protection |
| Name | Quantity |
| Semi-Automatic Wax Pattern Molding Machine | 20 sets |
| Fully Automatic Wax Pattern Molding Machine | 10 sets |
| CNC Milling Machine | 20 sets |
| Induction Melting Furnace | 9 sets |
| Sandblasting Machine | 20 sets |
| CNC Lathe | 120 sets |
| Laser Marking Machine | 4 sets |
| Manual Lathe | 1 set |
| Optical Emission Spectrometer (OES) | 1 set |
| Thread Gauge (CNC/Set) | 3 sets |
| Cutting Machine | 4 sets |
| |
