| Quantity: | |
|---|---|
SMLSCO-171
DN8-DN450
woven bag or as per customer’s
FOB/CFR/CIF，etc
T/T, L/C or as negotiation
Elements | TP304L(wt%) | TP316L (wt%) |
(C) Carbon, max | 0.035 | 0.035 |
(Mn) Manganese, max | 2 | 2 |
(P) Phosphorus, max | 0.045 | 0.045 |
(S) Sulfur, max | 0.03 | 0.03 |
(Si) Silicon, max | 1 | 1 |
(Ni) Nickel | 8.0 - 13.0 | 10.0 - 14.0 |
(Cr) Chromium | 18.0 - 20.0 | 16.0 - 18.0 |
(Mo) Molybdenum | N/A | 2.0 - 3.0 |
(Fe) Iron | Bal. | Bal. |
(Cu) Copper | N/A | N/A |
(N) Nitrogen | N/A | N/A |
Test | NTD(Ultrasonic test, Eddy Current test); |
Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test); | |
Metal Test(Metallographic Analysis, Impact Test-High/low temperature); | |
Chemical Analysis(Photoelectric Emission Spectroscopic) |
Construction building material, curtain wall bracket, guardrail/handrailing material,petroleum oil and gas transmission, coal, decoration, chemical engineering, food processing, agricultural use, indoor pipeline, water heater, boiler, etc.
Packaging Details:Woven bags or according to customer requirements
Port:SHANGHAI/NINGBO
Elements | TP304L(wt%) | TP316L (wt%) |
(C) Carbon, max | 0.035 | 0.035 |
(Mn) Manganese, max | 2 | 2 |
(P) Phosphorus, max | 0.045 | 0.045 |
(S) Sulfur, max | 0.03 | 0.03 |
(Si) Silicon, max | 1 | 1 |
(Ni) Nickel | 8.0 - 13.0 | 10.0 - 14.0 |
(Cr) Chromium | 18.0 - 20.0 | 16.0 - 18.0 |
(Mo) Molybdenum | N/A | 2.0 - 3.0 |
(Fe) Iron | Bal. | Bal. |
(Cu) Copper | N/A | N/A |
(N) Nitrogen | N/A | N/A |
Test | NTD(Ultrasonic test, Eddy Current test); |
Mechanical Test(Tension Test, Flaring Test, Flattening Test, Hardness Test, Hydraulic test); | |
Metal Test(Metallographic Analysis, Impact Test-High/low temperature); | |
Chemical Analysis(Photoelectric Emission Spectroscopic) |
Construction building material, curtain wall bracket, guardrail/handrailing material,petroleum oil and gas transmission, coal, decoration, chemical engineering, food processing, agricultural use, indoor pipeline, water heater, boiler, etc.
Packaging Details:Woven bags or according to customer requirements
Port:SHANGHAI/NINGBO
