Sch40 2205 Duplex Seamless Pipe Heavy Wall ASTM A790
| MOQ: | 1pc |
| Price: | Above 2usd/kg |
| Standard Packaging: | Bundles in woven bag/plywood case With plastic end caps |
| Delivery Period: | 2 weeks/container |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Capacity: | 1000 ton/month |
2205 Duplex Seamless Pipe
,Sch40 Duplex Seamless Pipe
,ASTM A790 Duplex Pipe
| Attribute | Value |
|---|---|
| Material | 2205/ S31803 |
| Certificates | ISO, PED |
| Package | Woven Bag |
| Manufacturing Method | Seamless |
| Standard | ASTM A790, ASTM A789 |
| Surface Treatment | Annealed & Pickled |
| Grade | S31803, 2205, 2507, TP 304; TP304H; TP304L; TP316; TP316L; TP 321; TP321H; TP317L; TP310S; TP347H |
|---|---|
| Standard | ASTM A790, ASTM A789, etc |
| Size | OD: 1/4" - 24" WT: Sch5s - XXS Length: Max.12M |
| Manufacturing Method | Seamless (Cold-drawn) |
| Surface Treatment | Annealed & Pickled |
| Length | Standard 6m / Customized available |
| Certification | ISO, PED certified |
2205 duplex stainless steel combines the characteristics of austenitic and ferritic steels, with excellent strength and corrosion resistance. It has outstanding resistance to chloride ion stress corrosion, pitting corrosion, and crevice corrosion, making it very suitable for high salt, high pressure, and high temperature working conditions.
In addition, 2205 has stable and reliable mechanical properties in high-pressure environments, and is widely used in industrial fields such as oil and gas, marine engineering, and chemical engineering that require strict material requirements.
2205 thick walled duplex steel seamless pipes are widely used in:
- Offshore oil platforms
- Subsea pipeline systems
- Chemical plant pipelines
- Desalination units
- Heat exchangers
- High-pressure process pipelines
Especially suitable for high chlorine, high salt, and high-pressure environments, it performs excellently in extending pipeline service life and reducing equipment maintenance costs, and is highly trusted by global customers, helping enterprises achieve safe and efficient production and operation.
- Long-term stock of over 2000 tons of seamless pipes
- TP2205 duplex steel thick walled pipes (Sch40) can be shipped in as little as 2 weeks for regular specifications
- Bulk procurement of high-quality raw materials effectively reduces overall costs
- All products undergo strict three-level quality inspection and 100% shipment inspection
- Stable and reliable product performance with PED certification
To ensure the quality stability of TP2205 thick walled duplex steel seamless pipes:
- Spectral composition analysis (PMI) to accurately detect the raw materials
- Eddy Current Testing during production to control surface and internal defects
- Finished product stage includes size measurement, hardness testing, liquid penetrant testing, and non-destructive testing (NDT)
| UNS Designation | C max | Si max | Mn max | P max | S max | Cr | Ni | Mo | N | Cu |
|---|---|---|---|---|---|---|---|---|---|---|
| S31803 2205 |
0.03 | 1 | 2 | 0.03 | 0.02 | 21.0 - 23.0 | 4.5 - 6.5 | 2.5 - 3.5 | 0.08 - 0.20 | - |
| S32205 2205 |
0.03 | 1 | 2 | 0.03 | 0.02 | 22.0 - 23.0 | 4.5 - 6.5 | 3.0 - 3.5 | 0.14 - 0.20 | - |
| S32750 2507 |
0.03 | 0.8 | 1.2 | 0.035 | 0.02 | 24.0 - 26.0 | 6.0 - 8.0 | 3.0 - 5.0 | 0.24 - 0.32 | 0.5 max |
| S32760 2507 |
0.05 | 1 | 1 | 0.03 | 0.01 | 24.0 - 26.0 | 6.0 - 8.0 | 3.0 - 4.0 | 0.20 - 0.30 | 0.50 -1.00 |
