316 Stainless Steel Hose Nipple 3/4" BSPT Class 150 Screwed Fitting
| MOQ: | 1pc |
| Price: | Above 2usd/kg |
| Standard Packaging: | Plywood case |
| Delivery Period: | 3 weeks/container |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Capacity: | 100 ton/month |
Detail Information
Brand Name
SMLSCO
Certification
ISO
Material:
Stainless Steel 316
Certificates:
ISO
Fitting Type:
Hose Nipple / Hose Barb Adapter
Connection:
Male Threaded BSPT X Hose Barb
Pressure Rating:
Class 150
Standard:
ISO 4144 (Dimensions, Ref.)
Highlight:
316 stainless steel hose nipple
,3/4 BSPT screwed fitting
,stainless steel casting fitting
Product Description
316 Stainless Steel Hose Nipple 3/4" BSPT Class 150 Screwed Fitting
Product Specifications
| Attribute | Value |
|---|---|
| Material | Stainless Steel 316 |
| Certificates | ISO |
| Fitting Type | Hose Nipple / Hose Barb Adapter |
| Connection | Male Threaded BSPT x Hose Barb |
| Pressure Rating | Class 150 |
| Standard | ISO 4144 (Dimensions, ref.) |
Product Overview
The stainless steel hose nipple serves as a crucial bridge between rigid pipes and flexible hoses. One end features a standard BSPT male thread for secure connection to piping systems, while the other end has a barbed socket (hose barb) that firmly holds hoses in place, even under high pressure conditions.
Key Features
- Secure Connection: BSPT threads create a tight interference fit when tightened into female ports
- Easy Installation: Threaded design allows for simple assembly and disassembly without welding
- Superior Material: 316 stainless steel offers excellent corrosion resistance, especially against chlorides
- Reliable Performance: Class 150 pressure rating ensures safe operation in industrial applications
- Standard Compliance: Manufactured to ISO 4144 dimensional standards
Material Advantages
316 stainless steel's molybdenum content provides exceptional resistance to chlorides and a wide range of chemicals. This prevents premature failure and leaks caused by media attack, ensuring longer service life and higher safety standards for your fluid conveyance systems.
Typical Applications
This 3/4" hose nipple is commonly used in:
- Chemical dosing systems
- Water treatment equipment
- General industrial fluid transfer
- Food and beverage processing
- Marine and shipping applications
- Mild chemical transportation systems
