F2205 Forged Socket Weld Coupling Class 9000 ASTM A182
| MOQ: | 1pc |
| Price: | Above 2usd/kg |
| Standard Packaging: | Plywood case |
| Delivery Period: | 3 weeks/container |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Capacity: | 100 ton/month |
Detail Information
Brand Name
SMLSCO
Certification
ISO PED
Material:
F2205
Certificates:
ISO,PED
Brand:
SMLSCO
Price Term:
FOB/CFR/CIF，etc
Payment:
T/T, L/C Or As Negotiation
Package:
Wooden Box
Highlight:
Forged Socket Weld Coupling
,F2205 Socket Weld Coupling
,ASTM A182 Forged Coupling
Product Description
Forged Coupling F2205 Socket Weld Class 9000 ASTM A182
| Attribute | Value |
|---|---|
| Material | F2205 |
| Certificates | ISO, PED |
| Brand | SMLSCO |
| Price Term | FOB/CFR/CIF, etc |
| Payment | T/T, L/C or as negotiation |
| Package | Wooden Box |
Product Overview
Forged Coupling F2205 Socket Weld Class 9000 ASTM A182 is a high-strength pipe fitting designed for demanding industrial applications.
Manufacturing Process
The excellent strength of SMLSCO pipe fittings comes from rigorous forging processes. We use standard round bars as raw materials, which are cut, heated, and then forged as a whole on a forging press. This process greatly refines the internal grain structure of the metal and eliminates potential metallurgical defects.
Subsequently, the forged blank undergoes heat treatment and precision CNC machining to form precise socket dimensions and groove angles, ensuring full compliance with the dimensional tolerance requirements of ASME B16.11.
Product Family
SMLSCO offers a complete range of forged pipe fittings to meet your diverse pipeline connection needs:
- Elbows and 45° elbows used for changing direction
- Tees and Crosses used for pipeline branching
- Couplings and Unions for straight line connections
- Caps and plugs used to seal the ends of pipelines
All fittings can be connected in two forms: Socket Weld and Threaded.
Product Specifications
Product Name: Forged Socket Weld Coupling
Material: Duplex F2205 / ASTM A182 F2205
Standard: ASME B16.11 / ASTM A182
Fitting Type: Full Coupling, Socket Weld (SW)
Pressure Rating: Class 9000
Process: Forged and Machined
Application: Subsea Equipment, High-Pressure Injection Systems
Size: Available from 1/8" to 4"
Why Choose SMLSCO?
SMLSCO's forged pipe fittings and flanges are produced at our exclusive manufacturing base - Wenzhou Yongheng Steel Industry. The factory has a monthly production capacity of 350 tons, equipped with 38 CNC lathes and 8 CNC drilling machines, ensuring the accuracy and efficiency of large-scale production.
Our factory quality system has passed ISO, PED, and the rigorous NORSOK M650 certification for the Norwegian petroleum industry. This indicates that we have the ability to continuously and stably provide forged pipe fittings that meet the highest quality standards for high-end industries such as chemical and offshore oil.
What is Forged Coupling?
Forged coupling is a high-strength pipe fitting used to connect two sections of pipes in a straight line. It is mainly divided into two forms:
- Full Coupling: With both ends having sockets or threads, used to connect two pipes
- Half Coupling: With one end as a socket or thread and the other end as a flat butt welding end, commonly used for direct welding on container walls or large diameter pipelines as a branch connection port for small diameters
What is Socket Weld Connection?
Socket welding is a reliable connection method designed specifically for high-pressure, small-diameter pipelines. During construction, insert the end of the pipeline into the socket of the pipe fitting, and reserve an expansion gap of about 1.5mm between the pipe end and the bottom of the socket. Then, perform corner welding on the outside of the pipe fitting.
This connection method has high strength, good airtightness, and can ensure the relative smoothness of the internal flow channel of the pipeline. It is widely used in industrial fields that have strict requirements for sealing and pressure bearing capacity.
