F321 Slip On Flange Stainless Steel Forged Flange For Pressure Vessel
| MOQ: | 1pc |
| Price: | Above 2usd/kg |
| Standard Packaging: | Plywood case |
| Delivery Period: | 3 weeks/container |
| Payment Method: | L/C,D/A,D/P,T/T,Western Union,MoneyGram |
| Supply Capacity: | 100 ton/month |
Detail Information
Brand Name
SMLSCO
Certification
ISO PED
Material:
F321
Product Name:
321 Forged Flange
Flange Type:
Slip On Flange
Use:
High Temperature Environment
Outer Diameter:
DN15 - DN2000
Package:
Plywood Cases
Highlight:
F321 Slip On Flange
,F321 Stainless Steel Forged Flange
,Pressure Vessel Slip On Flange
Product Description
F321 Slip On Flange Stainless Steel Forged Flange for Pressure Vessel
Product Specifications
| Attribute | Value |
|---|---|
| Material | F321 |
| Certificates | ISO, PED |
| Brand | SMLSCO |
| Price Term | FOB/CFR/CIF, etc |
| Payment | T/T, L/C or as negotiation |
| Package | Wooden Box |
Product Details
Product Name: Forged Slip-On Flange
Material: Stainless Steel F321 / UNS S32100
Standard: ASME B16.5 / ASTM A182
Flange Type: Slip-On (SO)
Process: Forged and Machined
Application: Pressure Vessel, High-Temperature Piping
Size & Rating: Full range of sizes and Class ratings available
Material: Stainless Steel F321 / UNS S32100
Standard: ASME B16.5 / ASTM A182
Flange Type: Slip-On (SO)
Process: Forged and Machined
Application: Pressure Vessel, High-Temperature Piping
Size & Rating: Full range of sizes and Class ratings available
SMLSCO Flange Supply Strategy
The core strategy of SMLSCO's flange business is to drive rapid manufacturing with semi-finished inventory. We reserve over 500 tons of various stainless steel forged flange blanks. This mode endows us with extremely high production flexibility, enabling us to quickly machine according to customers' needs for different materials, sizes, or special specifications, thereby achieving delivery cycles far faster than traditional "starting from scratch", providing you with reliable, fast, and cost-effective flange solutions.
Material Properties
| Steel grade | Y.S | T.S | EL. | HRB |
|---|---|---|---|---|
| 304 | ≥205 | ≥515-1035 | ≥40 | ≤92 |
| 304L | ≥205 | ≥520 | ≥40 | ≤90 |
| 316 | ≥620 | ≥310 | ≥30 | ≤95 |
| 316L | ≥480 | ≥177 | ≥40 | ≤90 |
| 321 | ≥205 | ≥515 | ≥40 | ≤95 |
| 347 | ≥205 | ≥515 | ≥40 | ≤92 |
Slip On Flange Characteristics
A neck flat welding flange, also known as a slip on flange, refers to a type of flange in which steel pipes are inserted into the inner ring of the flange for connection. It is fixed to the pipeline through two internal and external fillet welds, and its main advantage is that on-site alignment and installation are relatively convenient, which can eliminate the complex weld detection process. Compared with butt welded flanges, it has lower stiffness and load-bearing capacity, making it more suitable for working conditions with relatively mild temperature and pressure. It is an economical and practical connection choice.
SO Flange Application in Pressure Vessels
In the manufacturing of pressure vessels, F321 neck flat welding flanges are often used for connecting the pipe openings of equipment cylinders or heads. Thanks to the excellent high temperature resistance and intergranular corrosion resistance of F321 material, this type of flange is particularly suitable for pressure vessels that require high-temperature operation (425-850 °C) and cannot be subjected to subsequent heat treatment. They provide a convenient and reliable connection solution for the process inlet and outlet, manhole, observation port, etc. of containers under specific working conditions.
